eX-Perience Electronic Shock Absorbers - 50mm Lowered

Teknik eX-PERIENCE (50mm Low)

eX-PERIENCE (50mm Low)

50mm shorter than factory height. These performance piggyback shocks are an upgrade over the basic X-Cite shock absorber range, with full damping adjuster options. Designed as a jack of all trades for daily commuting, sporty cruising, tarmac touring, dirt roads and light adventuring, they replace the entire stock ESA electronically controlled damper assembly in a completely plug & play fitment that bolts to factory mounts and connects to the OEM wiring loom.

Lowered 50mm performance shocks for versatile riding

  • Improved stance and lower centre of gravity with 50mm reduced ride height
  • Separate precision high & low speed compression adjusters plus extended rebound range for tunable response
  • Robust internals: high flow 46mm main valving piston, over-sized 16mm chrome-moly shaft and heavy duty stainless bushes
  • Fully rebuildable cold-forged 6082 aluminium shock body with external reservoir for straightforward servicing

Recommended Pairings

Consider matching your shock upgrade with Suspension Tools.

Shop eX-PERIENCE (50mm Low)

Browse lowered eX-PERIENCE piggyback shocks and matching spring rates to suit rider weight and intended use.

3 Products Found
Tractive eX-PERIENCE Shock BMW R 1200 GS

Tractive eX-PERIENCE Shock BMW R 1200 GS

Front | Lowered -50mm
(SKU: 46BM13-P4142-TR)
Position (Front or Rear):   Front
Damping Adjustment Type:   Electronic & Compression High + Low Speed
Seat Height Change (mm):   Lowered -50
Shock Length Eye to Eye (mm):   372.0
Spring Rate Standard:   50 N/mm
Spring Option +1:   55-205
Spring Option -1:   48-205
Spring Option +2:   60-205
Manufacturer Note 1:   Side and/or center stand might be too long
Damping System:   Separated oil/gas with reservoir
Rebound Adjuster Position:   Cable exit (180 deg)
Low-speed Compression Adjuster Position:   13
High-speed Compression Adjuster Position:   13
Spring Preload Setting:   9
Preload Adjustment:   Mechanical
Spring Type:   Linear, included
Piston Diameter (mm):   46
Suspension Unit Type:   Shock
Fitted Spring:   50-205
Stroke Metal to Metal (mm):   79.0
Type Code:   eX-PERIENCE


Tractive eX-PERIENCE Shock BMW R 1250 GS Adventure

Tractive eX-PERIENCE Shock BMW R 1250 GS Adventure

Front | Lowered -50mm
(SKU: 46BM18-P4118-TR-01)
Position (Front or Rear):   Front
Damping Adjustment Type:   Electronic & Compression High + Low Speed
Seat Height Change (mm):   Lowered -50
Shock Length Eye to Eye (mm):   381.0
Spring Rate Standard:   55 N/mm
Spring Option -2:   48-205
Spring Option +1:   60-205
Spring Option -1:   50-205
Spring Option +2:   65-205
Manufacturer Note 1:   Side and/or center stand might be too long
Damping System:   Separated oil/gas with reservoir
Rebound Adjuster Position:   Cable exit (0 deg)
Low-speed Compression Adjuster Position:   10
High-speed Compression Adjuster Position:   10
Spring Preload Setting:   10
Preload Adjustment:   Mechanical
Spring Type:   Linear, included
Piston Diameter (mm):   46
Suspension Unit Type:   Shock
Fitted Spring:   55-205
Stroke Metal to Metal (mm):   92.0
Type Code:   eX-PERIENCE


Tractive eX-PERIENCE Shock BMW R 1250 GS

Tractive eX-PERIENCE Shock BMW R 1250 GS

Front | Lowered -50mm
(SKU: 46BM18-P4142-TR)
Position (Front or Rear):   Front
Damping Adjustment Type:   Electronic & Compression High + Low Speed
Seat Height Change (mm):   Lowered -50
Shock Length Eye to Eye (mm):   372.0
Spring Rate Standard:   55 N/mm
Spring Option +1:   60-180
Spring Option -1:   50-180
Spring Option +2:   65-180
Manufacturer Note 1:   Side and/or center stand might be too long
Damping System:   Separated oil/gas with reservoir
Rebound Adjuster Position:   Cable exit (0 deg)
Low-speed Compression Adjuster Position:   10
High-speed Compression Adjuster Position:   10
Spring Preload Setting:   10
Preload Adjustment:   Mechanical
Spring Type:   Linear, included
Piston Diameter (mm):   46
Suspension Unit Type:   Shock
Fitted Spring:   55-180
Stroke Metal to Metal (mm):   83.0
Type Code:   eX-PERIENCE


eX-PERIENCE (50mm Low)

50mm shorter than factory height. These performance piggyback shocks are an upgrade over the basic X-Cite shock absorber range, with full damping adjuster options. Designed as a jack of all trades for daily commuting, sporty cruising, tarmac touring, dirt roads and light adventuring, they replace the entire stock ESA electronically controlled damper assembly in a completely plug & play fitment that bolts to factory mounts and connects to the OEM wiring loom.

Lowered 50mm performance shocks for versatile riding

  • Improved stance and lower centre of gravity with 50mm reduced ride height
  • Separate precision high & low speed compression adjusters plus extended rebound range for tunable response
  • Robust internals: high flow 46mm main valving piston, over-sized 16mm chrome-moly shaft and heavy duty stainless bushes
  • Fully rebuildable cold-forged 6082 aluminium shock body with external reservoir for straightforward servicing
