The Ohlins FGHA1693 TTX 22 fork cartridge is designed to improve front-end control and rider confidence on selected KTM SX, SX-F and XC-F models. It focuses on delivering more refined damping feel for stability under braking and clearer feedback through the middle of the turn. Adjustment is provided so you can tailor the fork behaviour to suit your riding style and conditions.
Ohlins | Made to race, perfected to ride
Built around Ohlins suspension experience, this cartridge kit targets predictable damping performance and a composed front end. It is intended as a quality internal upgrade for riders chasing better feel and consistency from their fork.
Who this cartridge kit is for
- Riders wanting improved braking stability and front-end feedback
- Owners of compatible KTM SX, SX-F and XC-F models looking for a more controlled fork action
- Those who want the ability to fine-tune fork damping for changing conditions
Shock design & features
- TTX 22 fork cartridge design
- Refined damping characteristics aimed at improved mid-corner feel
- Premium internal components for consistent performance and durability
Tuning controls
- Separate compression and rebound damping adjustments
- Adjustability intended to make setup changes straightforward as conditions and preferences change
Before you install
- Confirm fitment against the exact model and year before ordering
- Professional installation is recommended to ensure correct assembly and setup
Öhlins Motorcycle Suspension Warranty
New Öhlins motorcycle shock absorbers, front forks and cartridge kits supplied by Teknik Motorsport are covered by the applicable Öhlins manufacturer’s warranty against defects in materials and workmanship.
Teknik Motorsport is an authorised Öhlins Service Centre and administers warranty claims in accordance with the Öhlins warranty conditions. The service intervals below form part of the maintenance requirements for Öhlins products supplied and supported by Teknik Motorsport.
This warranty is in addition to the consumer guarantees that apply under the Australian Consumer Law.
- Registered motorcycles — non-competition road use Five years, subject to correct application, installation, setup and servicing every: 20,000 km or two years, whichever occurs first.
- Registered motorcycles — adventure and light off-road use Five years, subject to correct application, spring rate, setup and servicing every: 10,000 km or annually, whichever occurs first.
- Unregistered or competition motorcycles Two years for eligible Öhlins MX and Enduro products, subject to inspection every ten hours and servicing every: 30 operating hours or annually, whichever occurs first.
Compliance with the applicable service interval is a condition of the Öhlins manufacturer’s warranty. Evidence of servicing may be required when a warranty claim is assessed.
A seal leak, loss of damping performance or internal wear arising after the prescribed service interval has been exceeded will be treated as a service or maintenance issue rather than a manufacturing defect.
Warranty repairs
Öhlins suspension products are designed to be serviced and repaired. Where a warranty claim is approved, the normal remedy is repair of the customer’s original suspension unit using genuine Öhlins replacement parts.
Replacement of a complete shock absorber, fork or cartridge kit is not automatic and would normally occur only where the product has suffered a manufacturing failure that cannot reasonably be repaired. This is at Ohlins discretion.
Öhlins spare parts and service kits
Öhlins spare parts, seals, bushes, service kits, springs, fluids and individual components are covered only against defects present when supplied.
No fixed age-based warranty applies to wear items, service parts or consumable components. Wear, deterioration, contamination, incorrect installation and damage caused by another component are not manufacturing defects.
Öhlins gives the customer a meaningful five-year warranty on products (Units), provided the suspension is maintained as suspension should be maintained. Teknik supports that warranty locally, can inspect the product properly, and can repair it with genuine parts rather than discarding it.
| SKU | FGHA1693 |
| Model # | TTX Cartridge kit |
| Barcode # | FGHA1693 |
| Brand | Ohlins |
| Shipping Weight | 5.0000kg |
| Shipping Size | 0.200 x 0.200 x 0.800m |
| Type | Units |
| Position (Front or Rear) | Front cartridge |
| Spring Rate | No Spring/s Supplied |
| Type Code | T22DR1C1 |
| Stroke Metal to Metal (mm) | 306.0 |
| Product Family | TTX 22 |
| Notes | 08765- series springs |
| Fitted Spring | Sold separately, see notes. |
| Rec. Ohlins Oil | 01330- |
