TracTive X-TREME BMW F 800 GS Shock
Rear | Standard | Orange/black | Hyd preload(SKU: 46BM08-T5535-TR)
$2,906.20
Find your Bike:
The TracTive X-TREME rear shock for the Yamaha Tenere 700 Rally uses a closed, pressurised architecture with a fixed reservoir and a spring. This model is configured with triple adjustability to support controlled tuning across varied riding conditions. It is supplied in a lowered configuration of 25 mm compared to standard ride height.
This shock is delivered with a factory baseline intended as a starting point. Final setup should be confirmed for rider weight, load and intended terrain, then adjusted methodically from that baseline.
Teknik Motorsport Pty Ltd Warranty terms for TracTive products.
This TracTive product has been assembled with the utmost care and tested according to ISO9001:2015 Quality system. In the unlikely event that the product does not fulfill your expectations because of faulty materials or manufacturing errors, please contact us through your dealer.
Teknik Motorsport Pty Ltd warrants that if, within 24 months of the date of sale the product is found to be defective as a result of manufacturing errors or faulty components, the product will be repaired free of charge by us, or by a TracTive approved repairer at our discretion.
Warranty covers the direct service material cost, service labour cost ($80/hr AUD) and shipping costs of the service partner. Other costs will be regarded on a case by case basis by Teknik Motorsport and TracTive.
When a claim is made under the warranty, the following conditions have to be met:
| SKU | 46YA25-T5147-TR |
| Model # | 46YA25-T5147-TR |
| Barcode # | 46YA25T5147TR |
| Brand | TracTive Suspension |
| Shipping Weight | 5.0000kg |
| Shipping Size | 0.200 x 0.200 x 0.400m |
| Unit Of Measure | ea |
| Type | X-TREME |
| Format | Rear |
If your Motorcycle is listed below, this product will suit:
| Position (Front or Rear) | Rear |
| Damping Adjustment Type | Rebound & Compression High + Low Speed |
| Seat Height Change (mm) | Lowered -25 |
| Shock Length Eye to Eye (mm) | 377 |
| Length Change (mm) | Lowered -25mm |
| Spring Rate Standard | 75 N/mm |
| Manufacturer Note 2 | Side and/or center stand might be too long |
| Spring Option -2 | 65-235 |
| Spring Option Maximum | 90-235 |
| Spring Option +1 | 80-235 |
| Spring Option -1 | 70-235 |
| Spring Option +2 | 85-235 |
| Manufacturer Note 1 | Does not fit base Tenere 700 |
| Damping Feature | PDSII anti-bottoming |
| Damping System | Separated oil/gas with reservoir |
| Rebound Adjuster Position | 12 (180 deg) |
| Low-speed Compression Adjuster Position | 12 |
| High-speed Compression Adjuster Position | 10 |
| Spring Preload Setting | 19 |
| Preload Adjustment | Mechanical |
| Spring Type | Linear, included |
| Piston Diameter (mm) | 46 |
| Suspension Unit Type | Shock |
| Fitted Spring | 75-235 |
| Notes | PDSII anti-bottoming |
| Stroke Metal to Metal (mm) | 94 |
| Type Code | X-TREME |
