The Ohlins FGYA1594 TTX 22 fork cartridge kit is designed to suit the Yamaha YZ 450F, focusing on controlled damping behaviour and clear front-end feel. It’s intended to help the fork remain composed through braking and cornering loads, with adjustments that let you tailor response to your riding. Built around Ohlins cartridge technology, it’s made for riders who want more consistent feedback from the front end.

Ohlins | Made to race, perfected to ride

Ohlins suspension components are developed with a strong engineering focus on damping control and repeatable adjustability. The TTX 22 platform aims to deliver predictable response across changing conditions, with tuning range to suit rider preference.

Who this kit is for

  • YZ 450F riders looking for improved front-end feedback and stability
  • Riders who want more control under braking and through mid-corner
  • Those who value adjustability to fine-tune feel and handling balance

Fork design & features

  • Ohlins TTX 22 fork cartridge system for controlled damping behaviour
  • Designed for a composed and communicative front end
  • Premium internal components for consistent performance and durability

Tuning controls

  • Separate compression and rebound adjustment to help dial in damping response
  • Adjustability aimed at making setup changes straightforward and repeatable

Before you install

  • Confirm compatibility with your Yamaha YZ 450F model and year before fitting
  • Professional installation is recommended to ensure correct assembly and setup
  • After installation, set sag and balance with the rear suspension to match your riding needs

Öhlins Motorcycle Suspension Warranty

New Öhlins motorcycle shock absorbers, front forks and cartridge kits supplied by Teknik Motorsport are covered by the applicable Öhlins manufacturer’s warranty against defects in materials and workmanship.

Teknik Motorsport is an authorised Öhlins Service Centre and administers warranty claims in accordance with the Öhlins warranty conditions. The service intervals below form part of the maintenance requirements for Öhlins products supplied and supported by Teknik Motorsport.

This warranty is in addition to the consumer guarantees that apply under the Australian Consumer Law.

  • Registered motorcycles — non-competition road use Five years, subject to correct application, installation, setup and servicing every: 20,000 km or two years, whichever occurs first.
  • Registered motorcycles — adventure and light off-road use Five years, subject to correct application, spring rate, setup and servicing every: 10,000 km or annually, whichever occurs first.
  • Unregistered or competition motorcycles Two years for eligible Öhlins MX and Enduro products, subject to inspection every ten hours and servicing every: 30 operating hours or annually, whichever occurs first.

Compliance with the applicable service interval is a condition of the Öhlins manufacturer’s warranty. Evidence of servicing may be required when a warranty claim is assessed.

A seal leak, loss of damping performance or internal wear arising after the prescribed service interval has been exceeded will be treated as a service or maintenance issue rather than a manufacturing defect.

Warranty repairs

Öhlins suspension products are designed to be serviced and repaired. Where a warranty claim is approved, the normal remedy is repair of the customer’s original suspension unit using genuine Öhlins replacement parts.

Replacement of a complete shock absorber, fork or cartridge kit is not automatic and would normally occur only where the product has suffered a manufacturing failure that cannot reasonably be repaired. This is at Ohlins discretion.

Öhlins spare parts and service kits

Öhlins spare parts, seals, bushes, service kits, springs, fluids and individual components are covered only against defects present when supplied.

No fixed age-based warranty applies to wear items, service parts or consumable components. Wear, deterioration, contamination, incorrect installation and damage caused by another component are not manufacturing defects.

Öhlins gives the customer a meaningful five-year warranty on products (Units), provided the suspension is maintained as suspension should be maintained. Teknik supports that warranty locally, can inspect the product properly, and can repair it with genuine parts rather than discarding it.

SKU FGYA1594
Model # TTX Cartridge kit
Barcode # FGYA1594
Brand Ohlins
Shipping Weight 5.0000kg
Shipping Size 0.200 x 0.200 x 0.800m
Type Units
See our Shipping Information See our Frequently Asked Questions

If your Motorcycle is listed below, this product will suit:

Position (Front or Rear) Front cartridge
Spring Rate No Spring/s Supplied
Type Code T22DR1C1
Fork Length (mm) 948.0
Stroke Metal to Metal (mm) 307.0
Product Family TTX 22
Notes 08762-series spring
Fitted Spring Sold separately, see notes.
Rec. Ohlins Oil 01330-
