The Ohlins FGHA1694 TTX 22 fork cartridge kit is designed to upgrade the front-end control of the KTM 450 SX-F across USA/CAN/AUS/NZ/MEX models. Built around Ohlins’ TTX 22 cartridge concept, it focuses on delivering consistent damping behaviour and clearer feedback at the bars. It’s intended for riders who want a more settled front end under load without complicating the setup process.

Ohlins | Made to race, perfected to ride

Ohlins suspension development is grounded in competition experience, with a focus on control, feel and repeatability. The FGHA1694 cartridge kit is a front-end solution aimed at improving damping quality and rider confidence through a more composed fork action.

Who this kit is for

  • KTM 450 SX-F riders looking for improved front-end stability and feedback
  • Riders who want more confidence under braking and through corners
  • Owners who prefer adjustable damping to suit different tracks and conditions

Fork design & features

  • TTX 22 fork cartridge kit design
  • Engineered to enhance braking stability and mid-corner feel through refined damping characteristics
  • Premium internal components aimed at consistent performance and durability

Tuning controls

  • Separate compression adjustment
  • Separate rebound adjustment

Before you install

  • Confirm fitment for KTM 450 SX-F in your listed market region (USA/CAN/AUS/NZ/MEX)
  • Installation requires suspension-specific tools and correct procedure for cartridge fitment
  • After installation, allow time to set sag and damping to suit rider preference and conditions

Öhlins Motorcycle Suspension Warranty

New Öhlins motorcycle shock absorbers, front forks and cartridge kits supplied by Teknik Motorsport are covered by the applicable Öhlins manufacturer’s warranty against defects in materials and workmanship.

Teknik Motorsport is an authorised Öhlins Service Centre and administers warranty claims in accordance with the Öhlins warranty conditions. The service intervals below form part of the maintenance requirements for Öhlins products supplied and supported by Teknik Motorsport.

This warranty is in addition to the consumer guarantees that apply under the Australian Consumer Law.

  • Registered motorcycles — non-competition road use Five years, subject to correct application, installation, setup and servicing every: 20,000 km or two years, whichever occurs first.
  • Registered motorcycles — adventure and light off-road use Five years, subject to correct application, spring rate, setup and servicing every: 10,000 km or annually, whichever occurs first.
  • Unregistered or competition motorcycles Two years for eligible Öhlins MX and Enduro products, subject to inspection every ten hours and servicing every: 30 operating hours or annually, whichever occurs first.

Compliance with the applicable service interval is a condition of the Öhlins manufacturer’s warranty. Evidence of servicing may be required when a warranty claim is assessed.

A seal leak, loss of damping performance or internal wear arising after the prescribed service interval has been exceeded will be treated as a service or maintenance issue rather than a manufacturing defect.

Warranty repairs

Öhlins suspension products are designed to be serviced and repaired. Where a warranty claim is approved, the normal remedy is repair of the customer’s original suspension unit using genuine Öhlins replacement parts.

Replacement of a complete shock absorber, fork or cartridge kit is not automatic and would normally occur only where the product has suffered a manufacturing failure that cannot reasonably be repaired. This is at Ohlins discretion.

Öhlins spare parts and service kits

Öhlins spare parts, seals, bushes, service kits, springs, fluids and individual components are covered only against defects present when supplied.

No fixed age-based warranty applies to wear items, service parts or consumable components. Wear, deterioration, contamination, incorrect installation and damage caused by another component are not manufacturing defects.

Öhlins gives the customer a meaningful five-year warranty on products (Units), provided the suspension is maintained as suspension should be maintained. Teknik supports that warranty locally, can inspect the product properly, and can repair it with genuine parts rather than discarding it.

SKU FGHA1694
Model # TTX Cartridge kit
Barcode # FGHA1694
Brand Ohlins
Shipping Weight 5.0000kg
Shipping Size 0.200 x 0.200 x 0.800m
Type Units
See our Shipping Information See our Frequently Asked Questions
Position (Front or Rear) Front cartridge
Spring Rate No Spring/s Supplied
Type Code T22DR1C1
Stroke Metal to Metal (mm) 306.0
Product Family TTX 22
Notes 08765- series springs
Fitted Spring Sold separately, see notes.
Rec. Ohlins Oil 01330-
