The Ohlins FGYA1694 TTX 22 fork cartridge is a front suspension upgrade built around controlled damping and clear feel at the bars. Designed for Yamaha YZ 450F fitment, it focuses on improving front-end support and consistency through the stroke. It is intended for riders who want more confidence under braking and a more settled front end when conditions change.

Ohlins | Made to race, perfected to ride

Ohlins cartridge kits are developed to deliver predictable damping behaviour and repeatable setup changes. The goal is a composed front end that communicates grip and stays stable as loads build.

Who this cartridge kit is for

  • YZ 450F riders chasing improved braking stability and front-end feedback
  • Riders who want a more controlled, consistent feel through corners
  • Anyone looking for adjustability to suit different tracks, terrain, or riding styles

Fork design & features

  • TTX 22 fork cartridge construction from Ohlins
  • Refined damping design aimed at a composed and communicative front end
  • High-quality internal components intended to support consistent damping performance

Tuning controls

  • Separate compression and rebound adjustment to help dial in feel and support
  • Adjustability intended to make changes straightforward during setup

Before you install

  • Confirm application and part number: FGYA1694
  • Plan installation by a suspension technician if you are not experienced with cartridge kits
  • After fitting, set sag and clicker positions methodically before making larger changes

Serviceability/lifecycle

Like any high-performance fork internals, cartridges benefit from routine servicing to keep damping consistent and to maintain seal and oil condition. Service intervals should be based on usage and conditions.

Öhlins Motorcycle Suspension Warranty

New Öhlins motorcycle shock absorbers, front forks and cartridge kits supplied by Teknik Motorsport are covered by the applicable Öhlins manufacturer’s warranty against defects in materials and workmanship.

Teknik Motorsport is an authorised Öhlins Service Centre and administers warranty claims in accordance with the Öhlins warranty conditions. The service intervals below form part of the maintenance requirements for Öhlins products supplied and supported by Teknik Motorsport.

This warranty is in addition to the consumer guarantees that apply under the Australian Consumer Law.

  • Registered motorcycles — non-competition road use Five years, subject to correct application, installation, setup and servicing every: 20,000 km or two years, whichever occurs first.
  • Registered motorcycles — adventure and light off-road use Five years, subject to correct application, spring rate, setup and servicing every: 10,000 km or annually, whichever occurs first.
  • Unregistered or competition motorcycles Two years for eligible Öhlins MX and Enduro products, subject to inspection every ten hours and servicing every: 30 operating hours or annually, whichever occurs first.

Compliance with the applicable service interval is a condition of the Öhlins manufacturer’s warranty. Evidence of servicing may be required when a warranty claim is assessed.

A seal leak, loss of damping performance or internal wear arising after the prescribed service interval has been exceeded will be treated as a service or maintenance issue rather than a manufacturing defect.

Warranty repairs

Öhlins suspension products are designed to be serviced and repaired. Where a warranty claim is approved, the normal remedy is repair of the customer’s original suspension unit using genuine Öhlins replacement parts.

Replacement of a complete shock absorber, fork or cartridge kit is not automatic and would normally occur only where the product has suffered a manufacturing failure that cannot reasonably be repaired. This is at Ohlins discretion.

Öhlins spare parts and service kits

Öhlins spare parts, seals, bushes, service kits, springs, fluids and individual components are covered only against defects present when supplied.

No fixed age-based warranty applies to wear items, service parts or consumable components. Wear, deterioration, contamination, incorrect installation and damage caused by another component are not manufacturing defects.

Öhlins gives the customer a meaningful five-year warranty on products (Units), provided the suspension is maintained as suspension should be maintained. Teknik supports that warranty locally, can inspect the product properly, and can repair it with genuine parts rather than discarding it.

SKU FGYA1694
Model # TTX Cartridge kit
Barcode # FGYA1694
Brand Ohlins
Shipping Weight 5.0000kg
Shipping Size 0.200 x 0.200 x 0.800m
Type Units
See our Shipping Information See our Frequently Asked Questions

If your Motorcycle is listed below, this product will suit:

Position (Front or Rear) Front cartridge
Spring Rate No Spring/s Supplied
Type Code T22DR1C1
Stroke Metal to Metal (mm) 308.0
Product Family TTX 22
Notes 08765- series springs
Fitted Spring Sold separately, see notes.
Rec. Ohlins Oil 01330-
