The Ohlins FGKT1794 TTX 22 fork cartridge kit is designed for riders chasing more controlled, consistent front-end damping in a KTM 450 SX-F. It focuses on improving feel through the stroke, helping the bike stay composed under load and offering clearer feedback at the bars. Built around Ohlins cartridge technology, it provides a more tunable fork setup compared with standard internals.

Ohlins | Made to race, perfected to ride

Developed from Ohlins racing experience, this cartridge kit is intended to deliver predictable damping behaviour and a wide adjustment range. It is a front-end upgrade aimed at riders who want greater confidence from their fork without turning the bike into a one-condition setup.

Who this kit is for

  • KTM 450 SX-F owners looking for improved front-end control and feedback
  • Riders who want a fork setup that can be tuned for changing conditions and preferences
  • Those targeting better stability and composure from the front end

Shock design & features

  • TTX 22 fork cartridge kit
  • Designed as an internal fork upgrade to refine damping control
  • Built to maintain consistent feel during demanding riding

Tuning controls

  • Separate compression and rebound adjustment
  • Supports more precise setup changes to suit rider preference

Before you install

  • Confirm compatibility with your KTM 450 SX-F market/region as listed
  • Professional installation is recommended to ensure correct assembly and setup
  • Plan time for initial adjustment after installation to match your riding needs

Is it right for you?

If you’re after a more controlled and adjustable fork feel on a KTM 450 SX-F, the FGKT1794 TTX 22 cartridge kit is a focused solution. It suits riders who value clear feedback and the ability to fine-tune damping rather than relying on a fixed, one-size setup.

Öhlins Motorcycle Suspension Warranty

New Öhlins motorcycle shock absorbers, front forks and cartridge kits supplied by Teknik Motorsport are covered by the applicable Öhlins manufacturer’s warranty against defects in materials and workmanship.

Teknik Motorsport is an authorised Öhlins Service Centre and administers warranty claims in accordance with the Öhlins warranty conditions. The service intervals below form part of the maintenance requirements for Öhlins products supplied and supported by Teknik Motorsport.

This warranty is in addition to the consumer guarantees that apply under the Australian Consumer Law.

  • Registered motorcycles — non-competition road use Five years, subject to correct application, installation, setup and servicing every: 20,000 km or two years, whichever occurs first.
  • Registered motorcycles — adventure and light off-road use Five years, subject to correct application, spring rate, setup and servicing every: 10,000 km or annually, whichever occurs first.
  • Unregistered or competition motorcycles Two years for eligible Öhlins MX and Enduro products, subject to inspection every ten hours and servicing every: 30 operating hours or annually, whichever occurs first.

Compliance with the applicable service interval is a condition of the Öhlins manufacturer’s warranty. Evidence of servicing may be required when a warranty claim is assessed.

A seal leak, loss of damping performance or internal wear arising after the prescribed service interval has been exceeded will be treated as a service or maintenance issue rather than a manufacturing defect.

Warranty repairs

Öhlins suspension products are designed to be serviced and repaired. Where a warranty claim is approved, the normal remedy is repair of the customer’s original suspension unit using genuine Öhlins replacement parts.

Replacement of a complete shock absorber, fork or cartridge kit is not automatic and would normally occur only where the product has suffered a manufacturing failure that cannot reasonably be repaired. This is at Ohlins discretion.

Öhlins spare parts and service kits

Öhlins spare parts, seals, bushes, service kits, springs, fluids and individual components are covered only against defects present when supplied.

No fixed age-based warranty applies to wear items, service parts or consumable components. Wear, deterioration, contamination, incorrect installation and damage caused by another component are not manufacturing defects.

Öhlins gives the customer a meaningful five-year warranty on products (Units), provided the suspension is maintained as suspension should be maintained. Teknik supports that warranty locally, can inspect the product properly, and can repair it with genuine parts rather than discarding it.

SKU FGKT1794
Model # TTX Cartridge kit
Barcode # FGKT1794
Brand Ohlins
Shipping Weight 5.0000kg
Shipping Size 0.200 x 0.200 x 0.800m
Type Units
See our Shipping Information See our Frequently Asked Questions
Position (Front or Rear) Front cartridge
Spring Rate No Spring/s Supplied
Type Code T22DR1C1
Stroke Metal to Metal (mm) 302.0
Product Family TTX 22
Notes 08765- series springs
Fitted Spring Sold separately, see notes.
Rec. Ohlins Oil 01330-
