The Tractive X-TREME shock for the Honda XL750 Transalp is a closed, pressurised rear shock designed for consistent damping control across changing conditions. Its architecture uses a separated oil and gas layout to reduce aeration and keep performance stable on long, rough rides. This model includes a remote reservoir and a hydraulic preload adjuster, allowing load changes to be managed without tools.

Design & features

  • Closed, pressurised design with oil and gas separation to help maintain consistent damping and reduce fade.
  • Remote reservoir configuration to support stable damping behaviour under sustained use.
  • Supplied with a spring and hydraulic preload adjuster for practical load and luggage changes.

Tuning Controls

  • Triple-adjustable damping: rebound and both low- and high-speed compression adjustment.
  • Hydraulic preload adjustment for fast ride-height/load support changes via the preload system (not a damping adjustment).

Base Setup (factory preset)

This shock is supplied with a baseline setup from Tractive intended to provide a balanced starting point for general use. Fine-tuning can be done using the external adjusters to suit rider mass, luggage and typical terrain.

Who is this for?

  • Riders who vary load (solo, luggage, or passenger) and want quick preload changes.
  • Owners looking for broader tuning range with separate rebound, low-speed compression and high-speed compression control.
  • Adventure and mixed-surface riders wanting consistent damping from a pressurised, separated oil/gas shock layout.

Before You Install

  • Confirm compatibility with your Honda XL750 Transalp model year and any accessories that may affect clearance around the remote reservoir and preload adjuster routing.
  • After installation, set sag and then fine-tune damping adjusters in small steps to match your typical riding conditions.

Serviceability/Lifecycle

As a closed, pressurised shock with a separated oil and gas system, it is designed to be serviced to maintain performance over time. Regular inspection for leaks, bushing wear, and hose/reservoir condition (where applicable) is recommended as part of routine maintenance.

Teknik Motorsport Pty Ltd Warranty terms for TracTive products.

This TracTive product has been assembled with the utmost care and tested according to ISO9001:2015 Quality system. In the unlikely event that the product does not fulfill your expectations because of faulty materials or manufacturing errors, please contact us through your dealer.

Teknik Motorsport Pty Ltd warrants that if, within 24 months of the date of sale the product is found to be defective as a result of manufacturing errors or faulty components, the product will be repaired free of charge by us, or by a TracTive approved repairer at our discretion.

Warranty covers the direct service material cost, service labour cost ($80/hr AUD) and shipping costs of the service partner. Other costs will be regarded on a case by case basis by Teknik Motorsport and TracTive.

 When a claim is made under the warranty, the following conditions have to be met:

  • You must have read the instructions carefully before mounting the product in the vehicle or adjusting the product.
  • The product has to be installed and adjusted as described in the instructions
  • The product must have been maintained and serviced in accordance with the recommendations in the manual. If not described in the manual, the recommended service intervals for regular street use: every 30.000 km or max 2 years, whichever is earlier.
  • Warranty shall apply only when TracTive original parts, procedures and tools have been used to service and/or repair, and if service and repair is performed by designated TracTive partners.
  • The product may not have been neglected, improperly used, altered or subjected to excessive loads. Excluded from warranty are normal wear, damage and rust.
  • A sales receipt or other proof of purchase originally eminating from Teknik Motorsport Pty Ltd. No warranty will be given on TracTive or Touratech products not purchased from or through Teknik Motorsport pty ltd.
  • Excluded from warranty are in particular products which are used in vehicles that are intended or suitable for taking part in sporting events, or have actually been used this way.
  • Recommended service interval for Motorsport applications: every season, or every 50 hours, every 10.000km or after any perceived loss in performance.
SKU 46HO23-T5523-TR
Model # 46HO23-T5523-TR
Barcode # 46HO23T5523TR
Brand TracTive Suspension
Shipping Weight 5.0000kg
Shipping Size 0.200 x 0.200 x 0.400m
Unit Of Measure ea
Type X-TREME
See our Shipping Information See our Frequently Asked Questions
Position (Front or Rear) Rear
Damping Adjustment Type Rebound & Compression High + Low Speed
Shock Options - Hydraulic Preload Adjuster Hydraulic with knob
Seat Height Change (mm) Lowered -25
Shock Length Eye to Eye (mm) 339.0
Spring Rate Standard 100 N/mm
Type Code X-TREME
Stroke Metal to Metal (mm) 75.0
Notes PDSII anti-bottoming
Fitted Spring 100-180
