The Tractive X-CITE Shock for the Kawasaki KLR 650 uses a closed, pressurised damper design to keep the oil and gas separated for more consistent damping over a wide range of conditions. This model is built around a 46 mm shock body and is configured with external rebound adjustment. It is supplied as a complete rear shock unit for replacement fitment.
Design & features
- Closed, pressurised construction to help maintain damping consistency by separating oil and gas.
- 46 mm shock format.
- Spring-equipped rear shock assembly.
Tuning Controls
- Rebound damping adjustment.
Base Setup (factory preset)
Delivered with a baseline setting intended to be tuned from there using the rebound adjuster to suit load, tyres, and typical riding conditions.
Before You Install
- Confirm compatibility with your exact KLR 650 variant and year range before purchase.
- Set sag and spring preload correctly after installation to establish a sound starting point for rebound tuning.
Serviceability/Lifecycle
As a pressurised shock absorber, periodic servicing helps maintain oil condition and gas pressure for consistent performance over time.
Need Help Choosing?
If you can share your model year, typical load (luggage/passenger), and riding mix, we can help confirm fitment and suggest a sensible starting approach to setup.
Teknik Motorsport Pty Ltd Warranty terms for TracTive products.
This TracTive product has been assembled with the utmost care and tested according to ISO9001:2015 Quality system. In the unlikely event that the product does not fulfill your expectations because of faulty materials or manufacturing errors, please contact us through your dealer.
Teknik Motorsport Pty Ltd warrants that if, within 24 months of the date of sale the product is found to be defective as a result of manufacturing errors or faulty components, the product will be repaired free of charge by us, or by a TracTive approved repairer at our discretion.
Warranty covers the direct service material cost, service labour cost ($80/hr AUD) and shipping costs of the service partner. Other costs will be regarded on a case by case basis by Teknik Motorsport and TracTive.
When a claim is made under the warranty, the following conditions have to be met:
- You must have read the instructions carefully before mounting the product in the vehicle or adjusting the product.
- The product has to be installed and adjusted as described in the instructions
- The product must have been maintained and serviced in accordance with the recommendations in the manual. If not described in the manual, the recommended service intervals for regular street use: every 30.000 km or max 2 years, whichever is earlier.
- Warranty shall apply only when TracTive original parts, procedures and tools have been used to service and/or repair, and if service and repair is performed by designated TracTive partners.
- The product may not have been neglected, improperly used, altered or subjected to excessive loads. Excluded from warranty are normal wear, damage and rust.
- A sales receipt or other proof of purchase originally eminating from Teknik Motorsport Pty Ltd. No warranty will be given on TracTive or Touratech products not purchased from or through Teknik Motorsport pty ltd.
- Excluded from warranty are in particular products which are used in vehicles that are intended or suitable for taking part in sporting events, or have actually been used this way.
- Recommended service interval for Motorsport applications: every season, or every 50 hours, every 10.000km or after any perceived loss in performance.
| SKU | 46KA08-R3201-TR |
| Model # | 46KA08-R3201-TR |
| Barcode # | 46KA08R3201TR |
| Brand | TracTive Suspension |
| Shipping Weight | 5.0000kg |
| Shipping Size | 0.200 x 0.200 x 0.400m |
| Unit Of Measure | ea |
| Type | X-CITE |
| Format | Rear |
If your Motorcycle is listed below, this product will suit:
- KAWASAKI KLR650E (KL650E) 2008
- KAWASAKI KLR650E (KL650E) 2009
- KAWASAKI KLR650E (KL650E) 2010
- KAWASAKI KLR650E (KL650E) 2011
- KAWASAKI KLR650E (KL650E) 2012
- KAWASAKI KLR650E (KL650E) 2013
- KAWASAKI KLR650E (KL650E) 2014
- KAWASAKI KLR650E (KL650E) 2015
- KAWASAKI KLR650E (KL650E) 2016
- KAWASAKI KLR650E (KL650E) 2017
- KAWASAKI KLR650E (KL650E) 2018
- KAWASAKI KLR650E (KL650E) 2019
- KAWASAKI KLR650E (KL650E) 2020
- KAWASAKI KLR650E (KL650E) 2021
- KAWASAKI KLR650E (KL650E) 2022
- KAWASAKI KLR650E (KL650E) 2023
- KAWASAKI KLR650E (KL650E) 2024
- KAWASAKI KLR650E (KL650E) 2025
- KAWASAKI KLR650E (KL650E) 2026
| Position (Front or Rear) | Rear |
| Damping Adjustment Type | Rebound |
| Seat Height Change (mm) | Standard Height |
| Shock Length Eye to Eye (mm) | 405.0 +6/-2 |
| Shock Length Eye to Eye (mm) | 405 +6/-2 |
| Spring Rate Standard | 60 N/mm |
| Spring Option -2 | 50-205 |
| Spring Option +1 | 65-205 |
| Spring Option -1 | 55-205 |
| Spring Option +2 | 70-205 |
| Manufacturer Note 1 | Not for lowered S model |
| Damping System | Separated oil/gas |
| Rebound Adjuster Position | 12 |
| Spring Preload Setting | 28 |
| Preload Adjustment | Mechanical |
| Spring Type | Linear, included |
| Piston Diameter (mm) | 46 |
| Suspension Unit Type | Shock |
| Fitted Spring | 60-205 |
| Stroke Metal to Metal (mm) | 84.0 |
| Type Code | X-CITE |
