The Ohlins HO345 STX 36 rear shock pair is built for Honda ADV 150 and ADV 160 riders looking for more controlled suspension behaviour from the back of the scooter. Using a gas-pressurised damping design, it is intended to maintain consistent damping under demanding conditions. Supplied as a rear twin-shock set, it supports stable chassis attitude and predictable feedback.

Ohlins | Made to race, perfected to ride

Ohlins suspension is developed with a focus on damping quality and repeatability. This STX 36 scooter application is aimed at improving composure and control without changing the character of the bike.

Who this shock is for

  • Honda ADV 150 / ADV 160 owners wanting clearer rear-end feel and better control over bumps and braking loads
  • Riders who carry luggage or a passenger and want more consistent support from the rear suspension
  • Anyone replacing tired OEM shocks with a serviceable performance unit

Shock design & features

This is a gas-pressurised, oil/gas separated shock design intended to reduce cavitation and help keep damping stable during repeated hits. It is supplied as a matched pair for rear twin-shock fitment.

Tuning controls

This model provides rebound damping adjustment to tailor how quickly the rear suspension extends after compression. It does not list external compression adjustment in the provided product data.

Before you install

  • Spacers are supplied in the box; refer to the manufacturer instructions for spacer positioning.
  • An alternative spring is also supplied in the box; confirm which spring is installed before setting sag or preload.
  • Use the recommended Ohlins oil as specified by Ohlins for servicing.

Serviceability / lifecycle

Like other Ohlins units, this shock pair is intended to be serviced to maintain performance over time. Plan periodic inspection and servicing based on use conditions and kilometres.

SKU HO345
Model # S36PR1
Brand Ohlins
Shipping Weight 5.0000kg
Shipping Size 0.300 x 0.300 x 0.500m
Type Units
See our Shipping Information See our Frequently Asked Questions
Position (Front or Rear) Rear Twin
Shock Length Eye to Eye (mm) 397.5
Spring Rate Standard 10.0 - 13.0 N/mm Progressive
Type Code S36PR1
Stroke Metal to Metal (mm) 121.5
Product Family STX 36 Scooter
Notes Spacers supplied in box: 01218-42 (2x) + 01218-19 (2x). See MI for spacers position Alternative spring 60480-11 supplied in box.
Fitted Spring: 60480-01
Rec. Ohlins Oil 01309-
